KTM 200 DUKE ABS

Thanks to an ultra-compact single-cylinder 4-stroke power plant and a lightweight tubular chassis, the KTM 200 DUKE packs a mighty punch. An updated predatory design proudly displays its BEAST-inspired DNA and shouts DUKE. Make no mistake – the KTM 200 DUKE is an out-and-out street prowling brawler.

TEST RIDE BOOK NOW

BSP. RM13888

product
product
product
product
product
product
product
product
product
product
product
product
product
  • COLOUR

GET DUKED WITH RIDING THE PRIDE OF EUROPEAN LEGACY

adventure
adventure
adventure

01 / PERFORMANCE

performance

ENGINE

Powered by a powerful single-cylinder engine, the KTM 200 DUKE not only delivers intoxicating acceleration but also everyday rideability. Boasting 19 kW (26 hp), it's the most powerful 4-stroke option in its class. Thanks to an updated airbox and exhaust, it meets the highest emission and noise standards, while providing maximum performance.

performance

CYLINDER HEAD

Just like the 1290 SUPER DUKE R, the four valves in the cylinder head of the KTM 200 DUKE are actuated by two overhead camshafts and ultra-hard, carbon coated cam followers. The result is an ultra-reliable, long-lasting engine that produces next-level power.

performance

INJECTION

The intricate engine design, state-of-the-art injection electronics and close-ratio, 6-speed transmission not only help the KTM 200 DUKE to achieve white-knuckle performance, but also extremely low fuel consumption. At the same time, thanks to the regulated catalytic converter, it produces minimal emissions, even when riding at full throttle.

performance

EXHAUST

The KTM 200 DUKE’s lightweight and precision-crafted exhaust system comprises of a side exhaust, link pipe and silencer. The three-chamber silencer has been positioned close to the bike’s overall center of gravity, improving balance and handling, whilst also delivering smooth, instant and beast-like power. Oh, and it looks angry as hell too.

02 / STYLE

performance

AGGRESIVE DESIGN

There's no denying the KTM 200 DUKE is 100% DUKE. Its aggressive-looking headlight, READY TO RACE stance and sharp lines make it a formidable presence on any street.

performance

HEADLIGHT

A new headlight gives the KTM 200 DUKE a menacing look. Not only does it look ultra-mean, its practical too, producing outstanding visibility for riding in low light or dark conditions.

performance

LCD DISPLAY

A 100% digital LCD display has everything you would expect from a state-of-the-art KTM motorcycle, including engaged gear, fuel gauge and service reminder information. It also comes with an RPM alert to indicate the optimum moment for up-shifting, just like those on the factory street racing machines.

03 / SAFETY

performance

ABS

Single channel BOSCH ABS comes as standard on the KTM 200 DUKE. This means you can ride assured knowing that should you have to brake hard and suddenly - the DUKE has your back.

04 / ERGONOMICS

performance

SEAT

The two-part seat offers first class sport riding ergonomics with maximum support for both rider and pillion.

performance

FUEL TANK

The innovative and ergonomic 13.4 liter steel fuel tank not only provides riders with perfect knee contact for attacking every corner, but also with an unbelievably long range, even when you ride as fast as you dare all day long.

TECHNICAL DETAILS

ENGINE
DESIGN1-cylinder 4-stroke engine, water-cooled
DISPLACEMENT200 cm³ (12.2 cu in)
STROKE49 mm (1.93 in)
BORE72 mm (2.83 in)
COMPRESSION RATIO11.5:1
CONTROLDOHC, 4 valves controlled via cam lever, chain drive
INTAKE VALVE DIAMETER28.5 mm (1.122 in)
EXHAUST VALVE DIAMETER24 mm (0.94 in)
VALVE CLEARANCE, INTAKE, COLD0.08 … 0.12 mm (0.0031 … 0.0047 in)
VALVE CLEARANCE, EXHAUST, COLD0.13 … 0.17 mm (0.0051 … 0.0067 in)
CRANKSHAFT BEARINGTwo ball bearings
CONROD BEARINGSleeve bearing
PISTONSCast light alloy
PISTON RINGS1 compression ring, 1 tapered compression piston ring, 1 oil scraper ring
ENGINE LUBRICATIONPressure circulation lubrication with 1 trochoidal pump
PRIMARY TRANSMISSION22:72
CLUTCHClutch in oil bath / mechanically activated
TRANSMISSION6-gear transmission, claw shifted
CHASSIS
FRAMELattice frame of steel tubes, powder-coated
FORKWP suspension
SHOCK ABSORBERWP suspension
FRONT BRAKE SYSTEMDisc brake with 4-piston brake caliper
REAR BRAKE SYSTEMDisc brake with single-pot brake caliper, floating
FRONT BRAKE DISC - DIAMETER300 mm (11.81 in)
REAR BRAKE DISC - DIAMETER230 mm (9.06 in)
FRONT BRAKE DISC - WEAR LIMIT4.5 mm (0.177 in)
REAR BRAKE DISC - WEAR LIMIT3.6 mm (0.142 in)
FRONT TYRE PRESSURE WHEN SOLO2.0 bar (29 psi)
REAR TYRE PRESSURE WHEN SOLO2.0 bar (29 psi)
FRONT TYRE PRESSURE WITH PASSENGER / FULL PAYLOAD2.0 bar (29 psi)
REAR TYRE PRESSURE WITH PASSENGER / FULL PAY LOAD2.2 bar (32 psi)
SECONDARY RATIO14:42
CHAIN5/8 x 1/4" (520) X-ring
STEERING HEAD ANGLE65°
WHEELBASE1,367 ± 15 mm (53.82 ± 0.59 in)
SEAT HEIGHT, UNLOADED800 mm (31.5 in)
DRY WEIGHT129.5 kg (285.5 lb.)
MAXIMUM PERMISSIBLE FRONT AXLE LOAD125 kg (276 lb.)
MAXIMUM PERMISSIBLE REAR AXLE LOAD210 kg (463 lb.)
MAXIMUM PERMISSIBLE OVERALL WEIGHT335 kg (739 lb.)
